20-24 kV
Outdoor Oil Type Current Transformer
Product parameters:
· Oil immersed current transformer
· Single phase
· Rated voltage: 15kV, 17.5kV, 20kV, 22kV, 24kV
· Metering class for CT: 0.2S, 0.2, 0.3, 0.5, 0.5S, 0.6
· Standard: IEC, ANSI, GB
· Type name: LJW-20, LJW-24, LJW-22
General
This outdoor oil immersed type current transformer used in 15kV, 17.5kV, 20kV, 22kV and 24kV power system, for measuring and protection.
It has been used in outdoor pole mounted and transmission line.
The current transformer is made from high quality transformer oil, amorphous alloy core for metering and high quality CRGO core for protection, primary and secondary use pure electrolytic copper, both winding and core have shielding
Standard
All UNISUN Electric instrument transformers are in conformity with IEC standards, and recommendations IEC 61869. Transformers in conformity with specific country standards can also be supplied. (IEEE C57.13, NBR6855).
Specification data sheet
Rated primary current(A) | Accuracy classes combination | Accuracy class and output (VA) | Short-time thermal current(kA/1s) | Rated dynamic current(kA) | ||||||
0.2s | 0.2 | 0.5s | 0.5 | 10P10 | 10P15 | 10P20 | ||||
5 | 0.2S/10P10 0.2S/10P15 0.2S/10P20 0.2/10P10 0.2/10P15 0.2/10P20 0.5/10P10 0.5/10P15 0.5/10P20 0.2S/0.2/10P10 0.2S/0.2/10P20 | 10 | 10 | 10 | 10 | 15 | 15 | 15 | 0.5 | 12.5 |
10 | 1 | 2.5 | ||||||||
15 | 1.5 | 3.75 | ||||||||
20 | 2 | 5 | ||||||||
25 | 2.5 | 6.25 | ||||||||
30 | 3 | 7.5 | ||||||||
40 | 4 | 10 | ||||||||
50 | 5 | 12.5 | ||||||||
75 | 7.5 | 18.75 | ||||||||
100 | 10 | 10 | 10 | 10 | 15 | 15 | 15 | 10 | 25 | |
150 | 15 | 37.5 | ||||||||
200 | 20 | 50 | ||||||||
30o | 30 | 75 | ||||||||
400 | 40 | 100 | ||||||||
500 | 50 | 75 | ||||||||
600 | 15 | 15 | 15 | 15 | 20 | 20 | 20 | 60 | 150 | |
800 | 80 | 200 | ||||||||
1000 | 15 | 20 | 15 | 30 | 30 | 30 | 20 | 80 | 200 | |
1200 | 80 | 200 | ||||||||
1500 | 80 | 200 | ||||||||
2000 | 80 | 200 |
- Products can be customized by customer requirements, above data is standard data, customized data please contact us.
Overall dimension
- Products can be customized by customer requirements, above dimension may change, correct dimension please contact us.
Waiting for your enquiry!
