Indoor LV Current Transformer
Product parameters:
· Indoor epoxy resin current transformer and indoor plastic casing current transformer
· Single phase, two phase or three phase.
· Rated voltage: 0.66kV, 0.75kV
· Metering class for CT: 0.2S, 0.2, 0.3, 0.5, 0.5S, 0.6
· Standard: IEC, ANSI, GB
· Type name: BH-0.66, LMK1-0.66
General
This indoor dry type current transformer is used in 0.66kV, 0.75kV. power system, for measuring and protection.
It has been used in cubicle switchgear or in bay-installed switching stations.
The current transformer is made from high temperature indoor epoxy resin, amorphous alloy core for metering and high quality CRGO core for protection, primary and secondary use pure electrolytic copper.
Standard
All UNISUN Electric instrument transformers are in conformity with IEC standards, and recommendations IEC 61869. Transformers in conformity with specific country standards can also be supplied. (IEEE C57.13, NBR6855).
Specification data sheet
Products can be customized by customer requirements, above data is standard data, customized data please contact us.Type
Rated current ratio
busbar
Number of bars
Rated load
Accuracy grade
Number of turns
-30B
30-75/5
5
0.2S、0.2 、0.5
turns
100/5-150/5
30 * 10
5
0.2S、0.2 、0.5
1
-30
15/5
5
0.2S、0.2 、0.5
10
20/5-40/5
5
0.2S、0.2 、0.5
turns
50/5
1
5
0.2S、0.2 、0.5
3
75/5
30 * 6
1
5
0.2S、0.2 、0.5
2
100/5
30 * 6
1
5
0.2S、0.2 、0.5
1
150/5-300/5
30 * 6
1
5
0.2S、0.2 、0.5
1
-40
100/5-150/5
40 * 10
1
5
0.2S、0.2 、0.5
1
200/5-250/5
40 * 10
1
5
0.2S、0.2 、0.5
1
300/5
40 * 10
1
5
0.2S、0.2 、0.5
1
400/5
40 * 10
1
5
0.2S、0.2 、0.5
1
500/5-600/5
40 * 10
1-2
10
0.2S、0.2 、0.5
1
-50
300/5-400/5
50 * 10
1-2
5
0.2S、0.2 、0.5
1
500/5-600/5
50 * 10
1-2
10
0.2S、0.2 、0.5
1
-60
400/5
60 * 10
1-2
5
0.2S、0.2 、0.5
1
500/5
60 * 10
1-2
5
0.2S、0.2 、0.5
1
600/5-800/5
60 * 10
1-2
5
0.2S、0.2 、0.5
1
1000/5
60 * 10
1-2
15
0.2S、0.2 、0.5
1
1200/5-1500/5
60 * 10
1-2
20
0.2S、0.2 、0.5
1
2000/5
60 * 10
1-2
30
0.2S、0.2 、0.5
1
-80
600/5-750/5
80 * 10
1-2
5
0.2S、0.2 、0.5
1
800/5
80 * 10
1-2
5
0.2S、0.2 、0.5
1
1000/5-1500/5
80 * 10
1-2
15
0.2S、0.2 、0.5
1
2000/5-2500/5
80 * 10
1-2
20
0.2S、0.2 、0.5
1
-100
800/5-1000/5
100 * 10
1-2
10
0.2S、0.2 、0.5
1
1200/5-3000/5
100 * 10
20
0.2S、0.2 、0.5
1
Overall dimension
- Products can be customized by customer requirements, above dimension may change, correct dimension please contact us.
Waiting for your enquiry!
