12kV Draw-out vcb

3-13.8kV

Draw-out type VCB

Product parameters:

· Indoor switchgear installation
· Three phase three wire
· Rated voltage: 3.3kV, 6kV, 10kV, 11kV, 12.5kV, 13.8kV
· Rated current: 630-4000A
· Short-circuit breaking current: 20-40kA
· Short-circuit closing current(peak): 50-100kA
· Installation type: Draw-out handcart type
· Standard: IEC, ANSI, GB
· Type name: UNVS1-12, ZN63-12

General

UNVS1-12 (ZN63) series indoor vacuum circuit breaker is a three-phase AC 50-60Hz, rated voltage of 3.3kV, 6kV, 10kV, 11kV, 12.5kV, 13.8kV indoor switchgear, control and protection for industrial and mining enterprises, power plants and substations , electrical facilities , and for frequent operation place .Adopting VET operating mechanism and circuit breaker integrated , design can be used as a fixed installation unit can also be equipped with special advance mechanism , the com position of handcart unit used. Some of the main circuit can use the whole solid seal post, in order to achieve smaller circuit breakers, high reliability , maintenance—free, can be equipped with UN-P28-12(GZS) and other handcart switch cabinet in the home can also be used with fixed XGN switchgear.

Standard
All UNISUN Electric breaker are in conformity with IEC standards, and recommendations IEC60694、IEC6227-100. Breakers in conformity with specific country standards can also be supplied. (IEEE, GB).

Specification data sheet



Rated voltage



kV



12



24



36



40.5

Rated frequency

Hz

50 -60

50 – 60

50 – 60

50 – 60



Rated normal current



A



630…4000



630.25



630…3150



630…3150



Rated short-circuit breaking current



kA



16.31.5



40



50



63



16.31.5



16.4



16.4



Rated short-circuit making current



kA



40.8



100



1254)



158



40.8



40.1



40.1



Rated duration of short- circuit4)





s





3





3





3





3





3





3





4

Fixed- / withdrawable

Version





• / •



• / •



• / •



•/ –



• / •



• / •



• / •

Max. overall dimensions (fixed Version)



mm

a

b

c





150-275

205-310

450-700

424

461-5996)





210-275

310

570-700

424

5996)





210-275

310

600-750

459

6088)





275

310

750

459

677





210-275

310

570-700

424

631-661





280/360

328

8957)/1000

555/6867)

1575





280/360

328

8957)/1000

555/6867)

1575

Weight

kg

73-105

94-180

147-260

265

100-110

290-365

290-365

Embedded Pole





Assembled Pole





  • Products can be customized by customer requirements, above data is standard data, customized data please contact us.

Overall dimension

  • Products can be customized by customer requirements, above dimension may change, correct dimension please contact us.
