12kV Side mounted VCB



Product parameters:

· Pole installation, full copper for connection
· Single Phase or Three phase
· Rated voltage: 3.3kV, 6kV, 10kV, 11kV, 12.5kV, 13.8kV
· Standard: IEC, ANSI, GB


This outdoor disconnector used in 3.3kV, 6kV, 10kV, 11kV, 12.5kV and 13.8kV power system, as power line cut and isolation function.

It has been used in outdoor pole mounted and transmission line.

It uses higher porcelain bushing, from bushing to metal have epoxy resin insulation, top busbar and connection bar use copper or brass.

Bottom installation base use high quality level galvanize.

All UNISUN Electric breaker are in conformity with IEC standards, and recommendations IEC60694、IEC6227-100. Breakers in conformity with specific country standards can also be supplied. (IEEE, GB).

Overall dimension


  • Products can be customized by customer requirements, above dimension may change, correct dimension please contact us.
