3-36kV
MV AVR
Product parameters:
- Smart automatic voltage regulator
- Single phase
- Rated voltage: 14.4kV; 19.92kV; 7.62kV; 13.8kV
- Standard: IEC, ANSI, GB
General
UNAVR single phase step voltage regulators are tap-changing autotransformers.
It regulates distribution line voltages from 10% raise (boost) to 10% lower (buck) in thirty-two steps of approximately 5/8% each. Voltage ratings are available from 2400 volts (60 kV BIL) to 34,500 volts (200 kV BIL) for 60 Hz and 50 Hz systems. Internal potential winding taps and an external ratio correction transformer are provided on all ratings so that each regulator may be applied to more than one system voltage. Smaller kVA sizes are supplied with support lugs for pole mounting and with substation or platform tie down provisions. Larger sizes are provided with substation bases with pad-mounting provisions.
Standard
All UNISUN transformers are in conformity with IEC standards, Transformers in conformity with specific country standards can also be supplied. (IEEE, GB)
Rated Voltage (KV) | Load Current | kVA | Dimensions(mm) | Oil | Untanking WGT(kgs) | Total WGT | ||||
A | B | C | D | E | ||||||
6.6 | 50 | 33 | 1893 | 1716 | 800 | 965 | 508 | 217 | 341 | 609 |
100 | 66 | 1892 | 1715 | 813 | 965 | 508 | 231 | 341 | 609 | |
150 | 99 | 1892 | 1892 | 853 | 995 | 508 | 250 | 380 | 700 | |
200 | 132 | 1975 | 1818 | 915 | 1232 | 559 | 303 | 445 | 860 | |
300 | 198 | 2070 | 2070 | 988 | 1333 | 611 | 500 | 678 | 1200 | |
400 | 264 | 2170 | 2170 | 1008 | 1353 | 680 | 550 | 870 | 1450 | |
500 | 330 | 2270 | 2270 | 1008 | 1353 | 750 | 620 | 1000 | 1780 | |
600 | 396 | 2270 | 2270 | 1220 | 1450 | 800 | 980 | 1200 | 2150 | |
11 | 50 | 55 | 1994 | 1817 | 694 | 890 | 508 | 208 | 389 | 661 |
100 | 110 | 1993 | 1818 | 864 | 1194 | 559 | 275 | 432 | 816 | |
150 | 165 | 2043 | 1869 | 1193 | 1161 | 610 | 370 | 560 | 1080 | |
200 | 220 | 2073 | 1920 | 1003 | 1320 | 635 | 360 | 649 | 1211 | |
300 | 330 | 2370 | 2208 | 998 | 1633 | 711 | 674 | 1007 | 1964 | |
400 | 440 | 2624 | 2462 | 1081 | 1784 | 838 | 1060 | 1059 | 2545 | |
500 | 550 | 2724 | 2724 | 1081 | 1784 | 838 | 1060 | 1200 | 2670 | |
600 | 660 | 2824 | 2824 | 1081 | 1784 | 838 | 1060 | 1300 | 2800 | |
15 | 50 | 75 | 1900 | 1900 | 1007 | 1010 | 610 | 344 | 500 | 875 |
100 | 150 | 2068 | 1869 | 1107 | 1110 | 610 | 344 | 573 | 1007 | |
150 | 225 | 2145 | 1971 | 1163 | 1278 | 660 | 479 | 707 | 1334 | |
200 | 300 | 2371 | 2209 | 1095 | 1445 | 711 | 555 | 910 | 1800 | |
300 | 450 | 2472 | 2310 | 1022 | 1701 | 762 | 791 | 1191 | 2252 | |
400 | 600 | 2700 | 2539 | 1275 | 1786 | 838 | 1098 | 1434 | 2904 | |
500 | 750 | 2750 | 2600 | 1275 | 1786 | 900 | 1098 | 1560 | 3200 | |
22 | 50 | 110 | 2093 | 1920 | 927 | 1270 | 635 | 371 | 455 | 945 |
100 | 220 | 2174 | 2031 | 1005 | 1405 | 711 | 550 | 783 | 1494 | |
150 | 330 | 2326 | 2183 | 1075 | 1467 | 737 | 659 | 1005 | 1873 | |
200 | 440 | 2396 | 2234 | 1036 | 1704 | 762 | 765 | 1223 | 2243 | |
300 | 660 | 2675 | 2414 | 1330 | 1848 | 889 | 1213 | 1566 | 3086 | |
33 | 50 | 165 | 2895 | 2754 | 799 | 1294 | 761 | 757 | 1080 | 1957 |
100 | 330 | 3100 | 2947 | 1003 | 1585 | 965 | 1480 | 1638 | 3249 | |
150 | 500 | 3142 | 2981 | 1285 | 1839 | 965 | 1567 | 1765 | 3616 | |
200 | 660 | 3264 | 3086 | 1166 | 1921 | 965 | 1648 | 1835 | 3915 |
- Products can be customized by customer requirements, above dimension may change, correct dimension please contact us
- Products can be customized by customer requirements, above data is standard data, customized data please contact us.
Waiting for your enquiry!
To Learn More info about Us!
