voltage transformer

10/11kV outdoor epoxy resin voltage transformer

33-40.5 kV

Outdoor Dry type Voltage Transformer

Product parameters:

· Outdoor epoxy resin voltage transformer
· Single Phase or Two Phase
· Rated voltage:  33kV, 35kV, 36kV, 40.5kV
· Metering class of PT: 0.2, 0.3, 0.5, 0.6
· Protection class of PT: 3P, 6P
· Standard: IEC, ANSI, GB
· Type name: JDZW-33, JDZXW-33, JDZXW-35

General

This outdoor epoxy resin type voltage transformer is used in 33kV, 35kV, 36kV and 40.5kV power system, for measuring and protection. Phase to grounding voltage transformer with R3 of primary system voltage.
It has been used in outdoor pole mounted and transmission line.

Both phase to phase voltage transformer and phase to grounding voltage transformer are made from high quality ultraviolet-proof epoxy resin, high quality CRGO core for metering and protection, primary and secondary use pure electrolytic copper, both winding and core have shielding processing.

Standard
All UNISUN Electric instrument transformers are in conformity with IEC standards, and recommendations IEC 61869. Transformers in conformity with specific country standards can also be supplied. (IEEE C57.13, NBR6855).

Specification data sheet

Type

Voltage ratio(kV)

Accuracy class and rated output (VA)

Limit output

(VA)

0.2

0.5

1

JDZW-33

33/0.1

25

50

100

400

JDZW-35

35/0.1

30

50

100

400

JDZXW-33

33000/√3/100/√3/100/3

45

90

100

960

JDZXW-35

35000/√3/100/√3/100/3

45

90

100

960

  • Products can be customized by customer requirements, above data is standard data, customized data please contact us.

Overall dimension

  • Products can be customized by customer requirements, above dimension may change, correct dimension please contact us.

Waiting for your enquiry!

Why Buy From Us

Professional Quality Guarantee
Easy and Affordable Payments
Best Product Guarantee

Our Production

The products are designed in strict accordance with IEC or ANSI standards, and the manufacturing steps meet the technological requirements

PT Core

Imported silicon steel sheet made of PT core, high quality insulation tape, high quality compression sponge, to ensure that resin shrinkage does not affect the performance of PT core, secondary use of high purity enameled wire.

Primary winding of PT

Mechanized winding secondary winding, all wire uses high purity copper enameled wire, each layer uses high quality insulating paper, to ensure that the layer withstand voltage qualified, to ensure the stability of partial discharge test.
